The goal of quickr is to make your R code run quicker.
R is an extremely flexible and dynamic language, but that flexibility and dynamicism can come at the expense of speed. This package lets you trade back some of that flexibility for some speed, for the context of a single function.
The main exported function is quick(), here is how you use it.
library(quickr)
convolve <- quick(function(a, b) {
declare(type(a = double(NA)),
type(b = double(NA)))
ab <- double(length(a) + length(b) - 1)
for (i in seq_along(a)) {
for (j in seq_along(b)) {
ab[i+j-1] <- ab[i+j-1] + a[i] * b[j]
}
}
ab
})quick() returns a quicker R function. How much quicker? Let’s
benchmark it! For reference, we’ll also compare it to a
pure-C
implementation.
slow_convolve <- function(a, b) {
declare(type(a = double(NA)),
type(b = double(NA)))
ab <- double(length(a) + length(b) - 1)
for (i in seq_along(a)) {
for (j in seq_along(b)) {
ab[i+j-1] <- ab[i+j-1] + a[i] * b[j]
}
}
ab
}
library(quickr)
quick_convolve <- quick(slow_convolve)
convolve_c <- inline::cfunction(
sig = c(a = "SEXP", b = "SEXP"), body = r"({
int na, nb, nab;
double *xa, *xb, *xab;
SEXP ab;
a = PROTECT(Rf_coerceVector(a, REALSXP));
b = PROTECT(Rf_coerceVector(b, REALSXP));
na = Rf_length(a); nb = Rf_length(b); nab = na + nb - 1;
ab = PROTECT(Rf_allocVector(REALSXP, nab));
xa = REAL(a); xb = REAL(b); xab = REAL(ab);
for(int i = 0; i < nab; i++) xab[i] = 0.0;
for(int i = 0; i < na; i++)
for(int j = 0; j < nb; j++)
xab[i + j] += xa[i] * xb[j];
UNPROTECT(3);
return ab;
})")
a <- runif (100000); b <- runif (100)
timings <- bench::mark(
r = slow_convolve(a, b),
quickr = quick_convolve(a, b),
c = convolve_c(a, b),
min_time = 2
)
timings
#> # A tibble: 3 × 6
#> expression min median `itr/sec` mem_alloc `gc/sec`
#> <bch:expr> <bch:tm> <bch:tm> <dbl> <bch:byt> <dbl>
#> 1 r 472.43ms 477.16ms 2.08 857KB 1.39
#> 2 quickr 2.64ms 2.7ms 366. 782KB 6.20
#> 3 c 918.2µs 1.01ms 991. 782KB 16.4
plot(timings) + bench::scale_x_bench_time(base = NULL)
In the case of convolve(), quick() returns a function approximately
200 times quicker, giving similar performance to the C function.
quick() can accelerate any R function, with some restrictions:
- Function arguments must have their types and shapes declared using
declare(). - Only atomic vectors, matrices, and array are currently supported:
integer,double,logical, andcomplex. - The return value must be an atomic array (e.g., not a list)
- Named variables must have consistent shapes throughout their lifetimes.
NAvalues are not supported.- Only a subset of R’s vocabulary is currently supported.
#> [1] != %% %/% & && ( *
#> [8] + - / : < <- <=
#> [15] = == > >= Fortran [ [<-
#> [22] ^ c cat cbind character declare double
#> [29] for if ifelse integer length logical matrix
#> [36] max min numeric print prod raw seq
#> [43] sum which.max which.min { | ||
Many of these restrictions are expected to be relaxed as the project matures. However, quickr is intended primarily for high-performance numerical computing, so features like polymorphic dispatch or support for complex or dynamic types are out of scope.
The shape and mode of all function arguments must be declared. Local and return variables may optionally also be declared.
declare(type()) also has support for declaring size constraints, or
size relationships between variables. Here are some examples of declare
calls:
declare(type(x = double(NA))) # x is a 1-d double vector of any length
declare(type(x = double(10))) # x is a 1-d double vector of length 10
declare(type(x = double(1))) # x is a scalar double
declare(type(x = integer(2, 3))) # x is a 2-d integer matrix with dim (2, 3)
declare(type(x = integer(NA, 3))) # x is a 2-d integer matrix with dim (<any>, 3)
# x is a 4-d logical matrix with dim (<any>, 24, 24, 3)
declare(type(x = logical(NA, 24, 24, 3)))
# x and y are 1-d double vectors of any length
declare(type(x = double(NA)),
type(y = double(NA)))
# x and y are 1-d double vectors of the same length
declare(
type(x = double(n)),
type(y = double(n)),
)
# x and y are 1-d double vectors, where length(y) == length(x) + 2
declare(type(x = double(n)),
type(y = double(n+2)))The Viterbi algorithm is an example of a dynamic programming algorithm
within the family of Hidden Markov Models
(https://en.wikipedia.org/wiki/Viterbi_algorithm). Here, quick()
makes the viterbi() approximately 50 times faster.
slow_viterbi <- function(observations, states, initial_probs, transition_probs, emission_probs) {
declare(
type(observations = integer(num_steps)),
type(states = integer(num_states)),
type(initial_probs = double(num_states)),
type(transition_probs = double(num_states, num_states)),
type(emission_probs = double(num_states, num_obs)),
)
trellis <- matrix(0, nrow = length(states), ncol = length(observations))
backpointer <- matrix(0L, nrow = length(states), ncol = length(observations))
trellis[, 1] <- initial_probs * emission_probs[, observations[1]]
for (step in 2:length(observations)) {
for (current_state in 1:length(states)) {
probabilities <- trellis[, step - 1] * transition_probs[, current_state]
trellis[current_state, step] <- max(probabilities) * emission_probs[current_state, observations[step]]
backpointer[current_state, step] <- which.max(probabilities)
}
}
path <- integer(length(observations))
path[length(observations)] <- which.max(trellis[, length(observations)])
for (step in seq(length(observations) - 1, 1)) {
path[step] <- backpointer[path[step + 1], step + 1]
}
out <- states[path]
out
}
quick_viterbi <- quick(slow_viterbi)
set.seed(1234)
num_steps <- 16
num_states <- 8
num_obs <- 16
observations <- sample(1:num_obs, num_steps, replace = TRUE)
states <- 1:num_states
initial_probs <- runif (num_states)
initial_probs <- initial_probs / sum(initial_probs) # normalize to sum to 1
transition_probs <- matrix(runif (num_states * num_states), nrow = num_states)
transition_probs <- transition_probs / rowSums(transition_probs) # normalize rows
emission_probs <- matrix(runif (num_states * num_obs), nrow = num_states)
emission_probs <- emission_probs / rowSums(emission_probs) # normalize rows
timings <- bench::mark(
slow_viterbi = slow_viterbi(observations, states, initial_probs,
transition_probs, emission_probs),
quick_viterbi = quick_viterbi(observations, states, initial_probs,
transition_probs, emission_probs)
)
timings
#> # A tibble: 2 × 6
#> expression min median `itr/sec` mem_alloc `gc/sec`
#> <bch:expr> <bch:tm> <bch:tm> <dbl> <bch:byt> <dbl>
#> 1 slow_viterbi 62.57µs 66.46µs 14550. 178KB 33.1
#> 2 quick_viterbi 1.76µs 1.93µs 503693. 0B 0
plot(timings)
Simulate how heat spreads over time across a 2D grid, using the finite difference method applied to the Heat Equation.
Here, quick() returns a function over 100 time faster.
diffuse_heat <- function(nx, ny, dx, dy, dt, k, steps) {
declare(
type(nx = integer(1)),
type(ny = integer(1)),
type(dx = integer(1)),
type(dy = integer(1)),
type(dt = double(1)),
type(k = double(1)),
type(steps = integer(1))
)
# Initialize temperature grid
temp <- matrix(0, nx, ny)
temp[nx / 2, ny / 2] <- 100 # Initial heat source in the center
# Time stepping
for (step in seq_len(steps)) {
# Apply boundary conditions
temp[1, ] <- 0
temp[nx, ] <- 0
temp[, 1] <- 0
temp[, ny] <- 0
# Update using finite differences
temp_new <- temp
for (i in 2:(nx - 1)) {
for (j in 2:(ny - 1)) {
temp_new[i, j] <- temp[i, j] + k * dt *
((temp[i + 1, j] - 2 * temp[i, j] + temp[i - 1, j]) /
dx ^ 2 + (temp[i, j + 1] - 2 * temp[i, j] + temp[i, j - 1]) / dy ^ 2)
}
}
temp <- temp_new
}
temp
}
quick_diffuse_heat <- quick(diffuse_heat)
# Parameters
nx <- 100L # Grid size in x
ny <- 100L # Grid size in y
dx <- 1L # Grid spacing
dy <- 1L # Grid spacing
dt <- 0.01 # Time step
k <- 0.1 # Thermal diffusivity
steps <- 500L # Number of time steps
timings <- bench::mark(
diffuse_heat = diffuse_heat(nx, ny, dx, dy, dt, k, steps),
quick_diffuse_heat = quick_diffuse_heat(nx, ny, dx, dy, dt, k, steps)
)
#> Warning: Some expressions had a GC in every iteration; so filtering is
#> disabled.
summary(timings, relative = TRUE)
#> Warning: Some expressions had a GC in every iteration; so filtering is
#> disabled.
#> # A tibble: 2 × 6
#> expression min median `itr/sec` mem_alloc `gc/sec`
#> <bch:expr> <dbl> <dbl> <dbl> <dbl> <dbl>
#> 1 diffuse_heat 112. 110. 1 1014. Inf
#> 2 quick_diffuse_heat 1 1 110. 1 NaN
plot(timings)
Here is quickr used to calculate a rolling mean. Note that the CRAN package RcppRoll already provides a highly optimized rolling mean, which we include in the benchmarks for comparison.
slow_roll_mean <- function(x, weights, normalize = TRUE) {
declare(
type(x = double(NA)),
type(weights = double(NA)),
type(normalize = logical(1))
)
out <- double(length(x) - length(weights) + 1)
n <- length(weights)
if (normalize)
weights <- weights/sum(weights)*length(weights)
for(i in seq_along(out)) {
out[i] <- sum(x[i:(i+n-1)] * weights) / length(weights)
}
out
}
quick_roll_mean <- quick(slow_roll_mean)
x <- dnorm(seq(-3, 3, len = 100000))
weights <- dnorm(seq(-1, 1, len = 100))
timings <- bench::mark(
r = slow_roll_mean(x, weights),
quickr = quick_roll_mean(x, weights = weights),
rcpp = RcppRoll::roll_mean(x, weights = weights)
)
#> Warning: Some expressions had a GC in every iteration; so filtering is
#> disabled.
timings
#> # A tibble: 3 × 6
#> expression min median `itr/sec` mem_alloc `gc/sec`
#> <bch:expr> <bch:tm> <bch:tm> <dbl> <bch:byt> <dbl>
#> 1 r 70.42ms 71.33ms 13.9 124.31MB 27.8
#> 2 quickr 3.12ms 3.23ms 302. 781.35KB 6.00
#> 3 rcpp 2.16ms 2.21ms 444. 4.38MB 5.98
timings$expression <- factor(names(timings$expression), rev(names(timings$expression)))
plot(timings) + bench::scale_x_bench_time(base = NULL)
When called in a package, quick() will pre-compile the quick functions
and place them in the ./src directory. Run devtools::load_all() or
quickr::compile_package() to ensure that the generated files in
./src and ./R are in sync with each other.
You can install the development version of quickr from GitHub with:
# install.packages("pak")
pak::pak("t-kalinowski/quickr")You will also need a C and Fortran compiler, preferably the same ones used to build R itself.
On macOS:
-
Make sure xcode tools and gfortran are installed, as described in https://mac.r-project.org/tools/. In Terminal, run:
sudo xcode-select --install curl -LO https://mac.r-project.org/tools/gfortran-12.2-universal.pkg sudo installer -pkg gfortran-12.2-universal.pkg -target /
On Windows:
- Install the latest version of Rtools
On Linux:
- The “Install Required Dependencies” section here provides detailed instructions for installing R build tools on various Linux flavors.
